Weight

132g

Cable Length

2m

Dimensions

97mm×160mm×64mm

Electrical

Interface

RS232/USB COM/Keyboard Interface

Input Voltage

DC+5V±5%

Operating Current

300mA (Max)

Startup Current

60mA

Standby Current

40mA

Decode Capability

Supported Symbologies

Australian Post, Aztec, BPO, Canada Post, Codabar, Codablock, Code   11/39/93, Code 128/EAN128, DataMatrix, Dutch Post, EAN.UCC Composite,   Interleaved 2 of 5, Japan Post, Matrix 2 of 5, MaxiCode, MicroPDF417, MSI   Code, PDF417, Planet, Plessey Code, Postnet, QR code, RSS, Standard 2 of 5,   Telepen, TLC 39, UPC/EAN

Environmental

Operating Temperature

-20℃~+60℃ (-4℉~140℉)

Storage Temperature

-30℃~+70℃ (-22℉~158℉)

Humidity

5%~95% (Non-condensing)

Light Tolerance

0~100,000 LUX

Performance

Light Source

630nm aiming laser + White LED illumination

Max Decoding Speed

25cm/s

Scan Resolution

640×480 pixels

Gray Scale

256 levels

Field of View (FOV)

45° Horizontal / 30° Vertical

DOF

Code 39 (5mil)

9.0-12.0cm

UPC/EAN (13mil)

3.0-26.5cm

Code 39 (20mil)

3.0-40.0cm

PDF417 (10mil)

5.0-20.5cm

Datamatrix (10mil)

5.2-23.0cm

Reliability

High Temp Test

60℃ for 30min

Low Temp Test

-20℃ for 30min

Thermal Cycling

24 cycles (30min high/low temp alternation)

Vibration

2000G/0.7ms/3-axis

Drop Test

1.2m free fall
